- Características de Hardware
- Interface: 1× Gigabit Ethernet (RJ-45) Port (Supports IEEE802.3at PoE)
- Botón Reset
- Fuente de Alimentación:
- 802.3at PoE
- 12 V DC
- Consumo de Energía:
- EU: 12 W
- US: 13.5 W
- Dimensiones (W x D x H): 9.6 × 9.6 × 2.5 in (243 × 243 × 64 mm)
- Tipo de Antena: Internal Omni
- 2.4 GHz: 2× 4 dBi
- 5 GHz: 2× 5 dBi
- Montaje: Ceiling / Wall Mounting (Kits Included)
- Características Inalámbricas
- Estándares Inalámbricos: IEEE 802.11ax/ac/n/g/b/a
- Frecuencia: 2.4 GHz and 5 GHz
- Tasa de Señal:
- 5 GHz: Up to 1201 Mbps
- 2.4 GHz: Up to 574 Mbps
- Funciones Inalámbricas:
- 1024-QAM
- 4× Longer OFDM Symbol
- OFDMA
- Multiple SSIDs (Up to 16 SSIDs, 8 for Each Band)
- Enable/Disable Wireless Radio
- Automatic Channel Assignment
- Transmit Power Control (Adjust Transmit Power on dBm)
- QoS(WMM)
- MU-MIMO
- Seamless Roaming
- Band Steering
- Load Balance
- Airtime Fairness
- Beamforming
- Rate Limit
- Reboot Schedule
- Wireless Schedule
- Wireless Statistics Based on SSID/AP/Client
- Seguridad Inalámbrica
- Captive Portal Authentication
- Access Control
- Wireless MAC Address Filtering
- Wireless Isolation Between Clients
- SSID to VLAN Mapping
- Rogue AP Detection
- 802.1X Support
- WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
- Potencia de Transmisión
- CE:
- 20 dBm (2.4 GHz, EIRP)
- 23 dBm (5 GHz, EIRP)
- FCC:
- 25 dBm (2.4 GHz)
- 25 dBm (5 GHz)
- Administración
- Omada App: Yes
- Centralized Management:
- Omada Cloud-Based Controller
- Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
- Cloud Access: Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
- Alertas de Correo Electrónico: Yes
- LED On/Off Control: Yes
- Management MAC Access Control: Yes
- SNMP: v1, v2c, v3
- System Logging: Local/Remote Syslog
- SSH: Yes
- Web-Based Management: HTTP/HTTPS
- L3 Management: Yes
- Multi-Site Management: Yes
- Management VLAN: Yes
- Otros
- Certificación: CE, FCC, RoHS
- Contenidos del Paquete:
- EAP620 HD
- Power Adapter
- Ceiling/Wall Mounting Kits
- Installation Guide
- Requisitos del Sistema: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Linux
- Ambiente:
- Operating Temperature: 0–40 °C (32–104 °F)
- Storage Temperature: -40–70 °C (-40–158 °F)
- Operating Humidity: 10–90% RH Non-Condensing
- Storage Humidity: 5–90% RH Non-Condensing
