CPU
INTEL SOCKET LGA1200 FOR 11TH GEN INTEL CORE PROCESSORS AND 10TH GEN INTEL CORE, PENTIUM GOLD AND CELERON PROCESSORS
SUPPORTS INTEL 14 NM CPU
SUPPORTS INTEL TURBO BOOST TECHNOLOGY 2.0 AND INTEL TURBO BOOST MAX TECHNOLOGY 3.0
REFER TO WWW.ASUS.COM FOR CPU SUPPORT LIST.
INTEL TURBO BOOST MAX TECHNOLOGY 3.0 SUPPORT DEPENDS ON THE CPU TYPES.
CHIPSET
INTEL H470 CHIPSET
MEMORY
2 X DIMM, MAX. 64GB, DDR4 3200(OC)/3000(OC)/2933/2800/2666/2400/2133 NON-ECC, UN-BUFFERED MEMORY
DUAL CHANNEL MEMORY ARCHITECTURE
SUPPORTS INTEL EXTREME MEMORY PROFILE (XMP)
10TH GEN INTEL CORE I7/I9 PROCESSORS SUPPORT 2933/2800/2666/2400/2133 NATIVELY, OTHERS WILL RUN AT THE MAXIMUM TRANSFER RATE OF DDR4 2666.
11TH GEN INTEL PROCESSORS SUPPORT 3200(OC)/3000(OC)/2933/2800/2666/2400/2133.
SUPPORTED MEMORY TYPES, DATA RATE (SPEED), AND NUMBER OF DRAM MODULES VARY DEPENDING ON THE CPU AND MEMORY CONFIGURATION, FOR MORE INFORMATION PLEASE REFER TO CPU/MEMORY SUPPORT LIST UNDER THE SUPPORT TAB OF PRODUCT INFORMATION SITE OR VISIT HTTPS://WWW.ASUS.COM/SUPPORT/.
GRAPHICS
1 X VGA PORT
1 X HDMI PORT
GRAPHICS SPECIFICATIONS MAY VARY BETWEEN CPU TYPES.
ONLY INTEL 11TH GEN PROCESSORS SUPPORT HDMI 2.1 WITH MAX. RESOLUTION OF 4K 60HZ, OTHERS WILL ONLY SUPPORT HDMI 1.4 WITH MAX. RESOLUTION OF 4K 30HZ. PLEASE REFER TO WWW.INTEL.COM FOR ANY UPDATES.
EXPANSION SLOTS
INTEL 11TH AND 10TH GEN PROCESSORS
1 X PCIE 4.0/3.0 X16 SLOT
- INTEL 11TH GEN PROCESSORS SUPPORT PCIE 4.0 X16
- INTEL 10TH GEN PROCESSORS SUPPORT PCIE 3.0 X16
INTEL H470 CHIPSET
1 X PCIE 3.0 X1 SLOT
STORAGE
TOTAL SUPPORTS 1 X M.2 SLOT AND 4 X SATA 6GB/S PORTS
INTEL H470 CHIPSET
M.2 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 3.0 X4 AND SATA MODES)
4 X SATA 6GB/S PORTS
ETHERNET
1 X REALTEK 1GB ETHERNET
USB
REAR USB (TOTAL 6 PORTS)
4 X USB 3.2 GEN 1 PORTS (4 X TYPE-A)
2 X USB 2.0 PORTS (2 X TYPE-A)
FRONT USB (TOTAL 6 PORTS)
1 X USB 3.2 GEN 1 HEADER SUPPORTS 2 ADDITIONAL USB 3.2 GEN 1 PORTS
2 X USB 2.0 HEADERS SUPPORT 4 ADDITIONAL USB 2.0 PORTS
AUDIO
REALTEK 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC
- SUPPORTS: JACK-DETECTION, MULTI-STREAMING, FRONT PANEL JACK-RETASKING
- SUPPORTS UP TO 24-BIT/192 KHZ PLAYBACK
AUDIO FEATURES
- AUDIO SHIELDING
- PREMIUM AUDIO CAPACITORS
- DEDICATED AUDIO PCB LAYERS
* A CHASSIS WITH AN HD AUDIO MODULE IN THE FRONT PANEL IS REQUIRED TO SUPPORT 7.1 SURROUND SOUND AUDIO OUTPUT.
BACK PANEL I/O PORTS
4 X USB 3.2 GEN 1 PORTS (4 X TYPE-A)
2 X USB 2.0 PORTS (2 X TYPE-A)
1 X VGA PORT
1 X HDMI PORT
1 X REALTEK 1GB ETHERNET PORT
3 X AUDIO JACKS
1 X PS/2 KEYBOARD/MOUSE COMBO PORT
INTERNAL I/O CONNECTORS
FAN AND COOLING RELATED
1 X 4-PIN CPU FAN HEADER
1 X 4-PIN CHASSIS FAN HEADER
POWER RELATED
1 X 24-PIN MAIN POWER CONNECTOR
1 X 8-PIN +12V POWER CONNECTOR
STORAGE RELATED
1 X M.2 SLOT (KEY M)
4 X SATA 6GB/S PORTS
USB
1 X USB 3.2 GEN 1 HEADER SUPPORTS 2 ADDITIONAL USB 3.2 GEN 1 PORTS
2 X USB 2.0 HEADERS SUPPORT 4 ADDITIONAL USB 2.0 PORTS
MISCELLANEOUS
1 X RGB HEADER
1 X CLEAR CMOS HEADER
1 X COM PORT HEADER
1 X FRONT PANEL AUDIO HEADER (AAFP)
1 X S/PDIF OUT HEADER
1 X SPEAKER HEADER
1 X SPI TPM HEADER (14-1PIN)
1 X 10-1 PIN SYSTEM PANEL HEADER
SPECIAL FEATURES
ASUS 5X PROTECTION III
- DIGI+ VRM
- LANGUARD
- OVERVOLTAGE PROTECTION
- SAFESLOT CORE
- STAINLESS-STEEL BACK I/O
ASUS Q-DESIGN
- Q-DIMM
- Q-LED CORE
- Q-SLOT
ASUS THERMAL SOLUTION
- ALUMINUM HEATSINK DESIGN
ASUS LIGHTING CONTROL
- RGB HEADER
SOFTWARE FEATURES
ASUS EXCLUSIVE SOFTWARE
ARMOURY CRATE
AI SUITE 3
- PERFORMANCE AND POWER SAVING UTILITY
TURBOV EVO
EPU
DIGI+ VRM
FAN XPERT
- EZ UPDATE
ASUS CPU-Z
NORTON 360 DELUXE (60 DAYS FREE TRIAL)
WINRAR
UEFI BIOS
ASUS EZ DIY
- ASUS CRASHFREE BIOS 3
- ASUS EZ FLASH 3
- ASUS UEFI BIOS EZ MODE
BIOS
128 MB FLASH ROM, UEFI AMI BIOS
MANAGEABILITY
WOL BY PME, PXE
ACCESSORIES
CABLES
2 X SATA 6GB/S CABLES
MISCELLANEOUS
1 X I/O SHIELD
1 X M.2 ANCHOR
DOCUMENTATION
1 X USER GUIDE
OPERATING SYSTEM
WINDOWS 10 64-BIT
FORM FACTOR
MICRO-ATX FORM FACTOR
8.9 INCH X 8.0 INCH ( 22.6 CM X 20.3 CM )
