CPU
INTEL SOCKET LGA1700 FOR 13TH GEN INTEL CORE AND 12TH GEN INTEL CORE, PENTIUM GOLD AND CELERON® PROCESSORS*
SUPPORTS INTEL TURBO BOOST TECHNOLOGY 2.0 AND INTEL TURBO BOOST MAX TECHNOLOGY 3.0**
* REFER TO WWW.ASUS.COM FOR CPU SUPPORT LIST.
** INTEL TURBO BOOST MAX TECHNOLOGY 3.0 SUPPORT DEPENDS ON THE CPU TYPES.
CHIPSET
INTEL Z790 CHIPSET
MEMORY
4 X DIMM, MAX. 128GB, DDR5
7800+(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800
NON-ECC, UN-BUFFERED MEMORY*
DUAL CHANNEL MEMORY ARCHITECTURE
SUPPORTS INTEL® EXTREME MEMORY PROFILE (XMP)
OPTIMEM II
* SUPPORTED MEMORY TYPES, DATA RATE (SPEED), AND NUMBER OF DRAM MODULES VARY DEPENDING ON THE CPU AND MEMORY CONFIGURATION, FOR MORE INFORMATION PLEASE REFER TO CPU/MEMORY SUPPORT LIST UNDER THE SUPPORT TAB OF PRODUCT INFORMATION SITE OR VISIT HTTPS://WWW.ASUS.COM/SUPPORT/
** NON-ECC, UN-BUFFERED DDR5 MEMORY SUPPORTS ON-DIE ECC FUNCTION.
GRAPHICS
1 X DISPLAYPORT**
1 X HDMI PORT***
* GRAPHICS SPECIFICATIONS MAY VARY BETWEEN CPU TYPES. PLEASE REFER TO WW.INTEL.COM FOR ANY UPDATES.
** SUPPORTS MAX. 8K@60HZ AS SPECIFIED IN DISPLAYPORT 1.4.
*** SUPPORTS 4K@60HZ AS SPECIFIED IN HDMI 2.1.
**** VGA RESOLUTION SUPPORT DEPENDS ON PROCESSORS OR GRAPHIC CARDS RESOLUTION.
EXPANSION SLOTS
INTEL 13TH AND 12TH GEN PROCESSORS
1 X PCIE 5.0 X16 SLOT
INTEL Z790 CHIPSET
1 X PCIE 4.0 X16 SLOT (SUPPORTS X4 OR X4/X4 MODE)
1 X PCIE 3.0 X1 SLOT
* PLEASE CHECK THE PCIE BIFURCATION TABLE
ON THE SUPPORT SITE (HTTPS://WWW.ASUS.COM/SUPPORT/FAQ/1037507/).
** TO ENSURE COMPATIBILITY OF THE DEVICE INSTALLED, PLEASE REFER TO HTTPS://WWW.ASUS.COM/SUPPORT/ FOR THE LIST OF SUPPORTED PERIPHERALS.
STORAGE
TOTAL SUPPORTS 4 X M.2 SLOTS AND 4 X SATA 6GB/S PORTS*
INTEL 13TH AND 12TH GEN PROCESSORS
M.2_1 SLOT (KEY M), TYPE 2242/2260/2280/22110 (SUPPORTS PCIE 4.0 X4 MODE)
INTEL Z790 CHIPSET
M.2_2 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 4.0 X4 MODE)
M.2_3 SLOT (KEY M), TYPE 2242/2260/2280/22110 (SUPPORTS PCIE 4.0 X4 MODE)
M.2_4 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 4.0 X4 AND SATA MODES)
4 X SATA 6GB/S PORTS
* INTEL RAPID STORAGE TECHNOLOGY SUPPORTS PCIE RAID 0/1/5/10, SATA RAID 0/1/5/10.
ETHERNET
1 X INTEL 2.5GB ETHERNET
ASUS LANGUARD
WIRELESS AND BLUETOOTH
WI-FI 6E
2X2 WI-FI 6E (802.11 A/B/G/N/AC/AX)
SUPPORTS 2.4/5/6GHZ FREQUENCY BAND*
BLUETOOTH V5.3
* WIFI 6E 6GHZ REGULATORY MAY VARY BETWEEN COUNTRIES.
** THE BLUETOOTH VERSION MAY VARY, PLEASE REFER TO THE WI-FI MODULE MANUFACTURERS WEBSITE FOR THE LATEST SPECIFICATIONS.
USB
REAR USB (TOTAL 10 PORTS)
1 X USB 3.2 GEN 2X2 PORT (1 X USB TYPE-C)
3 X USB 3.2 GEN 2 PORTS (2 X TYPE-A + 1 X USB TYPE-C)
4 X USB 3.2 GEN 1 PORTS (4 X TYPE-A)
2 X USB 2.0 PORTS (2 X TYPE-A)
FRONT USB (TOTAL 7 PORTS)
1 X USB 3.2 GEN 2X2 CONNECTOR (SUPPORTS USB TYPE-C)
1 X USB 3.2 GEN 1 HEADER SUPPORTS 2 ADDITIONAL USB 3.2 GEN 1 PORTS
2 X USB 2.0 HEADERS SUPPORT 4 ADDITIONAL USB 2.0 PORTS
AUDIO
ROG SUPREMEFX 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC S1220A
- IMPEDANCE SENSE FOR FRONT AND REAR HEADPHONE OUTPUTS
- SUPPORTS: JACK-DETECTION, MULTI-STREAMING, FRONT PANEL JACK-RETASKING
- HIGH QUALITY 120 DB SNR STEREO PLAYBACK OUTPUT AND 113 DB SNR RECORDING INPUT
- SUPPORTS UP TO 32-BIT/192 KHZ PLAYBACK*
AUDIO FEATURES
- SUPREMEFX SHIELDING TECHNOLOGY
- SAVITECH SV3H712 AMP
- REAR OPTICAL S/PDIF OUT PORT
- PREMIUM AUDIO CAPACITORS
- AUDIO COVER
*DUE TO LIMITATIONS IN HDA BANDWIDTH, 32-BIT/192 KHZ IS NOT SUPPORTED FOR 7.1 SURROUND SOUND AUDIO.
BACK PANEL I/O PORTS
1 X USB 3.2 GEN 2X2 PORT (1 X USB TYPE-C)
3 X USB 3.2 GEN 2 PORTS (2 X TYPE-A + 1 X USB TYPE-C)
4 X USB 3.2 GEN 1 PORTS (4 X TYPE-A)
2 X USB 2.0 PORTS (2 X TYPE-A)
1 X DISPLAYPORT
1 X HDMI PORT
1 X WI-FI MODULE
1 X INTEL 2.5GB ETHERNET PORT
5 X GOLD-PLATED AUDIO JACKS
1 X OPTICAL S/PDIF OUT PORT
1 X BIOS FLASHBACK BUTTON
1 X CLEAR CMOS BUTTON
INTERNAL I/O CONNECTORS
FAN AND COOLING RELATED
1 X 4-PIN CPU FAN HEADER
1 X 4-PIN CPU OPT FAN HEADER
1 X 4-PIN AIO PUMP HEADER
5 X 4-PIN CHASSIS FAN HEADERS
POWER RELATED
1 X 24-PIN MAIN POWER CONNECTOR
2 X 8-PIN +12V POWER CONNECTORS
STORAGE RELATED
4 X M.2 SLOTS (KEY M)
4 X SATA 6GB/S PORTS
USB
1 X USB 3.2 GEN 2X2 CONNECTOR (SUPPORTS USB TYPE-C)
1 X USB 3.2 GEN 1 HEADER SUPPORTS 2 ADDITIONAL USB 3.2 GEN 1 PORTS
2 X USB 2.0 HEADERS SUPPORT 4 ADDITIONAL USB 2.0 PORTS
MISCELLANEOUS
3 X ADDRESSABLE GEN 2 HEADERS
1 X AURA RGB HEADER
1 X CPU OVER VOLTAGE JUMPER
1 X FRONT PANEL AUDIO HEADER (AAFP)
1 X 20-3 PIN SYSTEM PANEL HEADER WITH CHASSIS INTRUDE FUNCTION
1 X THERMAL SENSOR HEADER
1 X THUNDERBOLT HEADER
SPECIAL FEATURES
EXTREME ENGINE DIGI+
- 5K BLACK METALLIC CAPACITORS
ASUS Q-DESIGN
- M.2 Q-LATCH
- PCIE SLOT Q-RELEASE
- Q-DIMM
- Q-LED (CPU [RED], DRAM [YELLOW], VGA [WHITE], BOOT DEVICE [YELLOW GREEN])
- Q-SLOT
ASUS THERMAL SOLUTION
- M.2 HEATSINK BACKPLATE
- M.2 HEATSINK
- VRM HEATSINK DESIGN
ASUS EZ DIY
- BIOS FLASHBACK BUTTON
- BIOS FLASHBACK LED
- CLEAR CMOS BUTTON
- CPU SOCKET LEVER PROTECTOR
- PROCOOL II
- PRE-MOUNTED I/O SHIELD
- SAFESLOT
- SAFEDIMM
AURA SYNC
- AURA RGB HEADER
- ADDRESSABLE GEN 2 HEADERS
SOFTWARE FEATURES
ROG EXCLUSIVE SOFTWARE
- GAMEFIRST VI
- ROG CPU-Z
- SONIC STUDIO III + SONIC STUDIO VIRTUAL MIXER + SONIC SUITE COMPANION
- SONIC RADAR III
- DTS SOUND UNBOUND
ASUS EXCLUSIVE SOFTWARE
ARMOURY CRATE
- AIDA64 EXTREME (60 DAYS FREE TRIAL)
- AURA CREATOR- AURA SYNC
- FAN XPERT 4 (WITH AI COOLING II)
- POWER SAVING
- TWO-WAY AI NOISE CANCELLATION
AI SUITE 3
- EASY OPTIMIZATION WITH AI OVERCLOCKING
- TPU
- DIGI+ VRM
- TURBO APP
- PC CLEANER
- SYSTEM INFORMATION
MYASUS
NORTON 360 FOR GAMERS
WINRAR
UEFI BIOS
AI OVERCLOCKING GUIDE
ASUS EZ DIY
- ASUS CRASHFREE BIOS 3
- ASUS EZ FLASH 3
- ASUS UEFI BIOS EZ MODE
FLEXKEY
MEMTEST86
BIOS
256 MB FLASH ROM, UEFI AMI BIOS
MANAGEABILITY
WOL BY PME, PXE
ACCESSORIES
CABLES
2 X SATA 6GB/S CABLES
ADDITIONAL COOLING KIT
1 X THERMAL PAD FOR M.2
MISCELLANEOUS
1 X ASUS WI-FI MOVING ANTENNAS
1 X CABLE TIES PACKAGE
1 X M.2 BACKPLATE Q-LATCH PACKAGE
1 X M.2 Q-LATCH PACKAGE
1 X ROG KEY CHAIN
1 X ROG STRIX STICKERS
1 X ROG STRIX THANK YOU CARD
2 X M.2 RUBBER PACKAGES
1 X M.2 BACKPLATE RUBBER
PACKAGE
DOCUMENTATION
1 X USER GUIDE
OPERATING SYSTEM
WINDOWS 11, WINDOWS 10 64-BIT
FORM FACTOR
ATX FORM FACTOR
12 INCH X 9.6 INCH ( 30.5 CM X 24.4 CM )
